With the development of the industry, the application of tray winding machine is more and more extensive. Here are the correct use methods of the winding machine summarized for you:
Usage method
Parameter setting
When the membrane rack is at the lower limit and there is no automatic operation, parameters can be set.
Manual operation automatic operation
1. Top ring setting
When the three position selector switch is in the “top circle” position, the counter displays the current top set circle number; at this time, each time you press the “value input” button once, the display value is increased by 1; when the display value is 9, if you press the “value input” button once again, the display value becomes 0; repeat the cycle. 1. Lower the membrane frame of the tray winding machine to the lower limit, place the goods of the tray winding machine on the turntable (as far as possible in the center of the turntable), place the membrane of the tray winding machine on the roll seat, and wear the membrane as required. Bolt the film of the tray winding machine to the bottom of the goods, and then press the “rotary table rotation” button of the tray winding machine to make the rotary table rotate. At this time, the film will wind the tray winding machine at the bottom of the goods. 1. Lower the membrane frame of the tray winding machine to the lower limit, place the goods of the tray winding machine on the rotary table of the winding machine (as far as possible in the center of the rotary table), place the membrane of the tray winding machine on the roll base, and wear the membrane as required. The winding film is bolted at the bottom of the goods. Press the “auto start” button, and the automatic operation starts. The rotary table starts to rotate, and the film is pulled out. At the same time, the rotary table starts to count, and the bottom winding is carried out first;
2. Bottom ring setting
When the three position selector switch is in the “bottom circle” position, the counter displays the current bottom set circle number; at this time, each time you press the “value input” button once, the display value is increased by 1; when the display value is 9, if you press the “value input” button once again, the display value becomes 0; repeat the cycle. 2. When the number of winding turns reaches the degree you need, pull the tray winding machine “up and down” to the “up” position, so that the membrane rack rises to the required position; at this time, the membrane will wind the tray winding machine on the top of the goods. When the number of winding turns reaches the level you need, turn the tray winding machine “up and down” to the “down” position, so that the membrane frame can be lowered to the lower limit.
2. After the bottom turns are completed, the membrane rack starts to rise; after the membrane rack rises to the top of the cargo (or upper limit position), the top winding starts, and the rotary table starts to count; after the top turns are completed, if the number of times is 0, the automatic operation ends; if the number of times is 1-9, the membrane rack starts to fall;
3. times setting
When the three position selector switch is in the “times” position, the counter displays the current previous and next values; at this time, each time you press the “value input” button once, the display value is increased by 1; when the display value is 9, if you press the “value input” button once again, the display value becomes 0; this is repeated. 3. Repeat the above process; finally, spring up the rotary button of the tray winding machine to stop the rotation of the rotary table; complete the primary packaging. Manually break the film and fix the film of tray winding machine on the goods.
We suggest that manual operation is mainly used for machine adjustment. 3. The number of times that the membrane rack lowers the bottom of the cargo (lower limit) increases by 1. By analogy, when the number of times up and down reaches the set value, the packaging process is completed. Manually break the film and fix the film of tray winding machine on the goods.
